ADI射頻微波I/Q調制器和解調器
發布時間：2020-11-24 15:49:52 瀏覽：1767
I/Q（In-phase/Quadrature）是一種射頻信號，最常見的I/Q調制/解調器是由90°分配器、兩個混頻器和0°分配器/合成器組成的。
當作為調制器時，輸入數據流被分離為獨立的I和Q信號，并在混頻器1和2中向上轉換。由于兩個混頻器的本振信號相位差為90°，混頻器1#和2#的輸出是正交的，兩個正交信號被合成在0°合成器中形成輸出。
當用作解調器時，本振信號從90°分配器的合成端輸入，射頻信號從0°分配器的合成端輸入，輸出I/Q信號在兩個混頻器中解碼。
調制/解調器的正交特性限制了電路的帶寬。
ADI射頻微波I/Q調制器和解調器可工作在高微波頻率下，具有高性能、寬工作頻率和靈活性的特點。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Freq BB 3 dB BW (typ) | IIP3 (typ) | OIP3 (typ) | Is (typ) | Vs (typ) |
| Hz | Hz | Hz | dBm | dBm | A |
|
ADMV1013 | 24G | 44G | 6G |
| 23 | 550m | 1.5 V, 1.8 V, 3.3 V |
ADMV1014 | 24G | 44G | 6G | 0 |
| 500m | 1.5 V, 1.8 V, 3.3 V |
LTC5594 | 300M | 9G | 1G | 30.8 | 40 | 470m | 5 V |
ADRF6821 | 450M | 2.8G | 1G |
| 32 | 545m | 3.3 V |
LTC5589 | 700M | 6G | 167M |
| 17.5 | 29.5m | 3 V, 3.3 V |
LTC5586 | 300M | 6G | 1G | 30 |
| 440m | 5 V |
ADRF6780 | 5.9G | 23.6G | 750M |
| 27 | 521m | 1.8 V, 3.3 V, 5 V |
ADRF6720-27 | 400M | 3G | 1G | 31.1 | 31.1 | 425m | 3.3 V |
LTC5599 | 30M | 1.3G | 57M |
| 20.8 | 28m | 3 V, 3.3 V |
ADRF6720 | 700M | 3G | 1G |
| 35.7 | 420m | 3.3 V |
ADRF6820 | 695M | 2.7G | 1.4G | 37 |
| 220m | 3.3 V, 5 V |
ADRF6755 | 300M | 2.31G | 600M | 20.5 | 21 | 350m | 5 V |
HMC1197 | 100M | 4G | 600M |
| 30 | 320m | 3.3 V, 5 V |
LTC5584 | 30M | 1.4G | 530M | 31 |
| 200m | 5 V |
HMC1097 | 100M | 6G | 700M |
| 29 | 170m | 5 V |
LTC5585 | 700M | 3G | 530M | 28.7 |
| 200m | 5 V |
ADRF6701 | 400M | 1.25G | 750M |
| 31.7 | 240m | 5 V |
ADRF6704 | 2.05G | 3G | 750M | 27.2 | 27.2 | 226m | 5 V |
ADRF6807 | 700M | 1.05G | 170M | 26.7 |
| 86m | 5 V |
ADRF6703 | 1.55G | 2.65G | 750M | 32.7 | 32.7 | 240m | 5 V |
ADRF6702 | 1.2G | 2.4G | 750M | 30.1 | 30.1 | 240m | 5 V |
ADRF6801 | 750M | 1.15G | 275M | 25 |
| 262m | 5 V |
ADRF6806 | 50M | 525M | 170M | 28.5 |
| 86m | 3 V, 5 V |
ADRF6850 | 100M | 1G | 300M | 22.5 |
| 350m | 3 V, 3.3 V |
LTC5588-1 | 200M | 6G | 500M |
| 30.9 | 303m | 3.3 V |
AD8346S | 800M | 2.5G |
|
|
|
| 3 V, 5 V |
ADRF6750 | 950M | 1.575G | 600M | 23 | 23 | 310m | 5 V |
HMC795 | 50M | 2.8G | 440M |
| 25 | 120m | 3.3 V, 5 V |
ADL5380 | 400M | 6G | 390M | 27.8 |
| 245m | 5 V |
LTC5598 | 5M | 1.6G | 400M |
| 25.5 | 165m | 5 V |
ADL5386 | 50M | 2.2G | 700M | 25 | 25 | 230m | 5 V |
ADF9010 |
|
|
|
| 24 |
| 3 V |
ADL5382 | 700M | 2.7G | 370M | 30.5 |
| 220m | 5 V |
ADL5375 | 400M | 6G | 750M | 23.4 | 26.8 | 194m | 5 V |
AD8339 | 0 | 50M | 50M | 31 |
| 35m | +/-5 |
ADL5387 | 30M | 2G | 240M | 31 |
| 180m | 5 V |
ADL5373 | 2.3G | 3G | 500M |
| 26 | 174m | 5 V |
ADL5590 | 869M | 900M | 250M |
| 29 | 170m | 5 V |
ADL5591 | 805M | 1.905G | 250M |
| 30 | 170m | 5 V |
LT5568-2 | 600M | 1.1G | 380M |
| 22.9 | 110m | 5 V |
ADL5371 | 500M | 1.5G | 500M |
| 27 | 175m | 5 V |
ADL5372 | 1.5G | 2.5G | 500M | 27 | 27 | 165m | 5 V |
ADL5370 | 300M | 1G | 500M |
| 24 | 205m | 5 V |
ADL5385 | 300M | 2.2G | 500M | 26 | 26 | 215m | 5 V |
LT5558 | 600M | 1.1G | 400M |
| 22.4 | 108m | 5 V |
LT5571 | 620M | 1.1G | 400M |
| 21.7 | 97m | 5 V |
LT5575 | 800M | 2.7G | 490M | 28 |
| 132m | 5 V |
AD8333 | 0 | 50M | 50M | 30 |
| 44m | +/-5 |
LT5568 | 600M | 1.2G | 380M |
| 22.9 | 117m | 5 V |
LT5518 | 1.5G | 2.4G | 400M |
| 22.8 | 128m | 5 V |
LT5572 | 1.5G | 2.5G | 460M |
| 21.6 | 120m | 5 V |
LT5528 | 1.5G | 2.4G | 400M |
| 21.8 | 125m | 5 V |
AD8349 | 700M | 2.7G | 160M | 21 | 21 | 135m | 5 V |
LT5546 | 40M | 500M | 17M | -1 |
| 24m | 1.8 V, 3.3 V, 5 V |
AD8348 | 50M | 1G | 125M | 28 |
| 51m | 3 V, 5 V |
LT5515 | 1.5G | 2.5G | 260M | 20 |
| 125m | 5 V |
LT5516 | 800M | 1.5G | 260M | 21.5 |
| 117m | 5 V |
LT5517 | 40M | 900M | 130M | 21 |
| 90m | 5 V |
LT5506 | 40M | 500M | 8.8M | -0.5 |
| 26.5m | 1.8 V, 3.3 V, 5 V |
AD8347 | 800M | 2.7G | 65M | 11.5 |
| 68m | 3 V, 5 V |
AD8345 | 140M | 1G | 80M | 25 | 25 | 62m | 3 V, 5 V |
LT5502 | 70M | 400M | 7.7M |
|
| 25m | 1.8 V, 3.3 V, 5 V |
AD8346 | 800M | 2.5G | 70M | 20 | 20 | 45m | 3 V, 5 V |
