Linear集成數字電源系統管理的μModule穩壓器
發布時間：2020-09-21 14:54:50 瀏覽：7220
Linear集成ICPMBusI2C串行接口的μModule?（微型模塊）電源穩壓器，也稱之為PSM（電源系統化管理），使控制系統設計人員和遠程操作人員能夠利用數字化系統總線來操作命令和監控設備的功率狀況和功能損耗。
Linear集成IC數字化電源系統化管理的μModule電源穩壓器與此同時能夠利用數字化方式調整電源技術參數，不需要像過去那樣調整物理硬件設備、電源電路和/或操作系統物料清單，從而縮減了產品上市時間和停機時長。Linear的μModule電源穩壓器在原型制造、構建和現場操作流程中簡化了操作系統特性、優化和數據建模。
Linear集成IC數字化電源系統化管理的μModule電源穩壓器采用數字化I2C/SMBus端口、LTpowerPlay?軟件和內部結構EEPROM，具備多個自定義選項。
深圳市立維創展科技是ADI \ Linear的代理商，以代理分銷庫存現貨ADI \ Linear為產品優勢，可提供當日發貨服務，歡迎咨詢。
產品型號 | Number of Outputs | Vin (min) V | Vin (max) V | Output Current (typ) A | Interface | ADC | DAC |
LTM4664 (dual output) | 2 | 30 | 58 | 25 | I2C, PMBUS | 10-bit | 10-Bit |
LTM4664 (single output) | 1 | 30 | 58 | 50 | I2C, PMBUS | 10-bit | 10-Bit |
LTM4680 (dual output) | 2 | 4.5 | 16 | 30 | I2C, PMBUS | 16-Bit | 12-Bit |
LTM4680 (single output) | 1 | 4.5 | 16 | 60 | I2C, PMBUS | 16-Bit | 12-Bit |
LTM4700 (dual output) | 2 | 4.5 | 16 | 50 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4700 (single output) | 1 | 4.5 | 16 | 100 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4678 (dual output) | 2 | 4.5 | 16 | 25 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4678 (single output) | 1 | 4.5 | 16 | 50 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4686 (dual output) | 2 | 4.5 | 17 | 10 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4686 (single output) | 1 | 4.5 | 17 | 20 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4686-1 (dual output) | 2 | 2.375 | 17 | 10 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4686-1 (single output) | 1 | 2.375 | 17 | 20 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4675 (dual output) | 2 | 4.5 | 17 | 9 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4675 (single output) | 1 | 4.5 | 17 | 18 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4676A (dual output) | 2 | 4.5 | 26.5 | 13 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4676A (single output) | 1 | 4.5 | 26.5 | 26 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4677 (dual output) | 2 | 4.5 | 16 | 18 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
LTM4677 (single output) | 1 | 4.5 | 16 | 36 | I2C, PMBUS, SMBUS | 16-Bit | 12-Bit |
