ADI分頻器、乘法器與檢波器
發布時間：2020-11-09 15:38:52 瀏覽：2194
ADI公司豐富的分頻器、倍頻器和檢波器產品提供了一系列高性能的解決方案，具有超低相位噪聲和更快的頻率鎖定時間等特性，以滿足現代技術的要求。
應用：
衛星通信
光纖產品
軍事和空間
測試和測量設備
點對點和點對多點無線電
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
產品型號 | Input Frequency (min) | Input Frequency (max) | Input Power (min) | Input Power (max) | Vs (typ) |
| Hz | Hz | dBm | dBm | V |
ADAR2001 | 2.5G | 10G | -25 | -10 | 2.5 |
HMC862A | 100M | 24G | -15 | 10 | 5 |
HMC3716 | 10M | 1.3G | -10 | 5 | 5 |
HMC1096 | 1.9G | 2.8G | -2 | 5 | 5 |
HMC1110 | 11.83G | 14.33G | 3 | 6 | 3 |
HMC1105 | 20G | 40G | 11 | 15 |
|
HMC988 | 0 | 4G |
|
| 3.3 |
HMC983 | 0 | 7G | -15 | 0 | 5 |
ADF5000 | 4G | 18G | -10 | 10 | 3.3 |
HMC695 | 2.85G | 3.3G | -15 | 5 | 5 |
HMC705 | 100M | 6.5G | -15 | 10 | 5 |
HMC984 | 0 | 350M | 3 | 12 | 5 |
ADF5002 | 4G | 18G | -10 | 10 | 3.3 |
HMC814-Die | 6.5G | 12.3G | 0 | 6 | 5 |
HMC814LC3B | 6.5G | 12.3G | 4 | 6 | 5 |
HMC905 | 400M | 6G | 0 | 10 | 3.3 |
HMC942 | 12G | 15.5G | 4 | 6 | 4.5 |
ADF5001 | 4G | 18G | -10 | 10 | 3.3 |
HMC794 | 200M | 2G | -2 | 10 | 5 |
HMC-XTB110 | 24G | 30G | 10 | 15 |
|
HMC598 | 11G | 23G | 5 | 6 | 5 |
HMC-XDB112 | 10G | 15G | 10 | 15 |
|
HMC561-Die | 4G | 10.5G | 0 | 6 | 5 |
HMC561LP3 | 4G | 10.5G | 0 | 6 | 5 |
HMC573 | 4G | 11G | 5 | 8 | 5 |
HMC575 | 3G | 4.5G | 3 | 6 | 5 |
HMC576-Die | 9G | 14.5G | -2 | 6 | 5 |
HMC576LC3B | 9G | 14.5G | 3 | 6 | 5 |
HMC577 | 13.5G | 15.5G | 5 | 6 | 5 |
HMC578-Die | 12G | 16.5G | 0 | 6 | 5 |
HMC578LC3B | 11.5G | 16.5G | 3 | 6 | 5 |
HMC579 | 16G | 23G | 3 | 6 | 5 |
HMC447 | 10G | 26G | -15 | 10 | 5 |
HMC368 | 4.5G | 8G | 2 | 2 | 5 |
HMC448-Die | 9.5G | 12.5G | -4 | 6 | 5 |
HMC448LC3B | 10G | 12.5G | -4 | 6 | 5 |
HMC369 | 4.95G | 6.35G | 0 | 5 | 5 |
HMC492 | 200M | 18G | -20 | 10 | 5 |
HMC493 | 200M | 18G | -20 | 10 | 5 |
HMC494 | 200M | 18G | -20 | 10 | 5 |
HMC370 | 3.6G | 4.1G | -15 | 5 | 5 |
HMC432 | 200M | 8G | -12 | 12 | 3 |
HMC433 | 200M | 8G | -12 | 12 | 3 |
HMC434 | 200M | 8G | -10 | 12 | 3 |
HMC437 | 100M | 7G | -12 | 12 | 5 |
HMC438 | 100M | 7G | -15 | 10 | 5 |
HMC439 | 10M | 1.3G | -10 | 10 | 5 |
HMC443 | 2.45G | 2.8G | -15 | 5 | 5 |
HMC444 | 1.238G | 1.4G | -15 | 5 | 5 |
HMC445 | 618.8M | 687.5M | -15 |
| 5 |
HMC361-Die | 200M | 12G | -10 | 2 | 5 |
HMC361G8 | 10M | 13G | -15 | 0 | 5 |
HMC361S8G | 400M | 10G | -15 | 10 | 5 |
HMC362-Die | 200M | 12G | -10 | 2 | 5 |
HMC362S8G | 200M | 12G | -15 | 10 | 5 |
HMC363-Die | 200M | 13G | -10 | 2 | 5 |
HMC363G8 | 200M | 12G | -15 | 10 | 5 |
HMC363S8G | 200M | 13G | -10 | 2 | 5 |
HMC365-Die | 200M | 14G | -10 | 3 | 5 |
HMC365G8 | 200M | 14G | -10 | 5 | 5 |
HMC365S8G | 200M | 14G | -10 | 3 | 5 |
HMC394 | 100M | 2.2G | -15 | 10 | 5 |
