E2V半導體HIREL電子接口
發布時間：2020-11-17 16:23:52 瀏覽：6741
E2V半導體HIREL電子接口是基于Hirel設計的許多OEM源和芯片生產一系列DLA認可的接口產品。此外，Hirel還重新創建了幾個接口和邏輯產品，包括流行的線路驅動器、接收器和外圍設備驅動器。
E2V半導體Hirel的大多數接口功能都是經過DLA認證的，并且有多種包裝類型，包括陶瓷DIP、LCC、Flatpack和金屬罐。資格選擇最多可達MIL-PRF-38535。
深圳立維創展科技是E2V的經銷商，主要供給E2V數模轉換器和半導體，E2V的應用領域包括通信、自動化、發現、醫療、環保等。價格優勢，歡迎咨詢。
詳情了解E2V 芯片請點擊：http://www.lunliu2.cn/brand/26.html
或聯系我們的銷售工程師：0755-83050846 QQ: 3312069749
Standard Interface
Description | Package | SMD_Number | Generic Part Numbers | Die Mfg |
Bus Transceiver, 8-Bit, Bidirectional, with 8-Bit Parity Gen/Checker | DIP, FP, LCC | 5962-89535 | 54F657 | Fairchild National |
Bus Transceiver, Dual Asynchronous | DIP, FP, LCC | 5962-89532 | 2692 | Philips |
Bus Transceiver, Quad, Non-inverting, with 3-State Outputs | DIP, FP, LCC | 5962-86834 | 54F243 | Fairchild National |
Line Driver, Quad, RS-422 / RS-423 | DIP, FP, LCC | 5962-86721 | 26LS30 1691A | QP Semi |
Line Driver, Quad Differential, High speed | DIP, FP, LCC | 5962-78023 | 26LS31 | QP Semi |
Line Receiver, Quad Differential | DIP, FP, LCC | 5962-78020 | 26LS32 26LS33 | QP Semi |
Peripheral Driver, Dual AND, CMOS-Comp, with O-C Outputs | CAN, DIP | 5962-88631 | 1631 | QP Semi |
Peripheral Driver, Dual NAND, CMOS-Comp, with O-C Outputs | CAN, DIP | 5962-90522 | 1632 | QP Semi |
Peripheral Driver, Dual OR, CMOS-Comp, with O-C Outputs | CAN, DIP | N/A | 1633 | QP Semi |
Peripheral Driver, Dual NOR, CMOS-Comp, with O-C Outputs | CAN, DIP | 5962-89821 | 1634 | QP S |
