PICO電源EMI電感器
發布時間：2021-01-18 17:00:58 瀏覽：7113
PICO電源的EMI共?？刂齐姼芯?span style="font-family:Tahoma">Mil-PRF-27標準s級和5級生產制造。PICO電源EMI電感特別適用于電源開關穩壓電源、交直流電源、DC-DC電源及其各類對清除電磁干擾有至關重要意義的電器設備制造商。鑒于MOSFET、SCR、繼電器、三端雙向晶閘管開關的開關操作，電氣設備會引起噪聲。根據運用PICO電源EMI電感器，反饋到電源線的噪聲被降到最低到可接受的程度，而且噪聲不會影響在設施上工作的其他設施。同一根電源線。
深圳市立維創展科技是PICO公司的分銷商。提供進口PICO電源模塊、軍用電源模塊、高壓電源模塊、小型變壓器、MIL-PRF-21038/27規格變壓器、脈沖變壓器、400 MHz電力變壓器、MIL-STD-1553接口變壓器、音頻變壓器、功率電感、微型功率電感、EMI電感、薄DC-直流電源模塊、軍用DC-DC電源模塊、磚塊DC-DC電源模塊、高壓DC-DC、AC-DC電源模塊、開關直流電源模塊、隔離電源模塊、航空電源模塊等功能電源模塊和功率轉換器。原裝產品進口，質量保證，歡迎咨詢。
詳情了解PICO電源模塊請點擊：http://www.lunliu2.cn/brand/15.html
或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674
Part Number | Inductance (Each Winding) | Leakage Inductance Typical(μH) | Current IRMS (AMP) Temp. Rise 25°C | IRMS (AMP) Temp. Rise 40°C | IRMS (AMP) Temp Rise 50°C | IRMS (AMP) Temp. Rise 60°C | RDC. (OHM) Each Winding | Approximate Leakage Inductance | Size |
37100 | 100 Micro Henry | 1 |
|
|
|
|
|
| 1 |
37110 | 150 Micro Henry | 1 |
|
|
|
|
|
| 1 |
37120 | 200 Micro Henry | 1 |
|
|
|
|
|
| 1 |
37130 | 300 Micro Henry | 2 |
|
|
|
|
|
| 1 |
37140 | 400 Micro Henry | 3 |
|
|
|
|
|
| 1 |
37150 | 500 Micro Henry | 4 |
|
|
|
|
|
| 1 |
37160 | 1000 Micro Henry | 6 |
|
|
|
|
|
| 1 |
37170 | 1500 Micro Henry | 7 |
|
|
|
|
|
| 1 |
37200 | 100 Micro Henry | 1 |
|
|
|
|
|
| 2 |
37210 | 150 Micro Henry | 1 |
|
|
|
|
|
| 2 |
37220 | 200 Micro Henry | 2 |
|
|
|
|
|
| 2 |
37230 | 300 Micro Henry | 3 |
|
|
|
|
|
| 2 |
37240 | 400 Micro Henry | 3 |
|
|
|
|
|
| 2 |
37250 | 500 Micro Henry | 4 |
|
|
|
|
|
| 2 |
37260 | 1000 Micro Henry | 6 |
|
|
|
|
|
| 2 |
37270 | 1500 Micro Henry | 7 |
|
|
|
|
|
| 2 |
37300 | 100 Micro Henry | 1 |
|
|
|
|
|
| 3 |
37310 | 150 Micro Henry | 2 |
|
|
|
|
|
| 3 |
37320 | 200 Micro Henry | 2 |
|
|
|
|
|
| 3 |
37330 | 300 Micro Henry | 3 |
|
|
|
|
|
| 3 |
37340 | 400 Micro Henry | 4 |
|
|
|
|
|
| 3 |
37350 | 500 Micro Henry | 4 |
|
|
|
|
|
| 3 |
37360 | 1000 Micro Henry | 5 |
|
|
|
|
|
| 3 |
37370 | 1500 Micro Henry | 7 |
|
|
|
|
|
| 3 |
37400 | 100 Micro Henry | 2 |
|
|
|
|
|
| 4 |
37410 | 150 Micro Henry | 2 |
|
|
|
|
|
| 4 |
37420 | 200 Micro Henry | 3 |
|
|
|
|
|
| 4 |
37430 | 300 Micro Henry | 3 |
|
|
|
|
|
| 4 |
37440 | 400 Micro Henry | 5 |
|
|
|
|
|
| 4 |
37450 | 500 Micro Henry | 6 |
|
|
|
|
|
| 4 |
37460 | 1000 Micro Henry | 9 |
|
|
|
|
|
| 4 |
37470 | 1500 Micro Henry | 9 |
|
|
|
|
|
| 4 |
46123 | 12 Milli Henry | 12000 | 0.1 | 0.12 | 0.15 |
| 6.6 | 220 | 1 |
46143 | 6.75 Milli Henry | 6750 | 0.14 | 0.17 | 0.21 |
| 3.71 | 123.8 | 1 |
46163 | 3 Milli Henry | 3000 | 0.2 | 0.25 | 0.31 |
| 1.65 | 55 | 1 |
46183 | 1.5 Milli Henry | 1500 | 0.29 | 0.35 | 0.44 |
| 0.82 | 27.5 | 1 |
46203 | 750 Micro Henry | 750 | 0.41 | 0.5 | 0.62 |
| 0.41 | 13.8 | 1 |
46223 | 550 Micro Henry | 550 | 0.47 | 0.57 | 0.71 |
| 0.31 | 10.3 | 1 |
46243 | 375 Micro Henry | 375 | 0.57 | 0.69 | 0.86 |
| 0.26 | 9 | 1 |
46263 | 185 Micro Henry | 185 | 0.96 | 1 | 1.25 |
| 0.13 | 5 | 1 |
46283 | 75 Micro Henry | 75 | 1.29 | 1.57 | 1.95 |
| 0.05 | 3.5 | 1 |
46405 | 20 Milli Henry | 20000 | 0.14 | 0.15 |
| 0.18 | 4.5 | 160 | 1 |
46410 | 17.5 Milli Henry | 17500 | 0.15 | 0.16 |
| 0.2 | 3.94 | 140 | 1 |
46415 | 15 Milli Henry | 15000 | 0.16 | 0.17 |
| 0.21 | 3.4 | 120 | 1 |
46420 | 10 Milli Henry | 10000 | 0.19 | 0.21 |
| 0.26 | 2.3 | 80 | 1 |
46425 | 7.5 Milli Henry | 7500 | 0.22 | 0.24 |
| 0.3 | 1.7 | 60 | 1 |
46430 | 5 Milli Henry | 5000 | 0.28 | 0.3 |
| 0.37 | 1.1 | 40 | 1 |
46435 | 2.5 Milli Henry | 2500 | 0.39 | 0.42 |
| 0.52 | 0.56 | 20 | 1 |
46440 | 1 Milli Henry | 1000 | 0.61 | 0.66 |
| 0.81 | 0.23 | 8 | 1 |
46445 | 750 Micro Henry | 750 | 0.6 | 0.7 |
| 0.8 | 0.21 | 6 | 1 |
