ADI包絡檢波器
發布時間：2022-09-28 16:44:17 瀏覽：1339
ADI包絡檢測器系列產品提供了直流電到67GHz頻率范圍之內瞬時檢測與信號幅值檢測。這些快速反應，溫度補償機器設備提供更多的輸出格式，如瞬時包絡輸出電壓，峰值保持，或數字閾值檢測標識。ADI包絡檢測器特別適合于各種各樣應用，如功率放大器偏置操控中的包絡追蹤，脈沖檢測，接收器的輸入保護，大功率放大器保護，及其IQ調制器的LO漏校準。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.lunliu2.cn/brand/25.html
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Input Dynamic Range (typ) | Temp Drift (typ) | Is (typ) | Vs+ (min) | Vs+ (max) | Package |
| Hz | Hz | dB | dB | A | V | V |
|
ADL6012 | 2G | 67G | 40 | 1 | 28.6m | 3.15 | 5.25 | 10-Lead LFCSP (2mm x 3mm w/ EP) |
ADL6010S | 500M | 43.5G | 45 | 0.3 | 3m | 4.78 | 5.25 | CER LDLESS CHIP W/HEATSINK |
ADL5910 | 0 | 6G | 45 | 0.5 | 3.5m | 3.15 | 3.45 | 16-Lead LFCSP (3mm x 3mm w/ EP) |
ADL5904 | 0 | 6G | 45 | 0.5 | 3.5m | 3.15 | 3.45 | 16-Lead LFCSP (3mm x 3mm w/ EP) |
ADL6010 | 500M | 43.5G | 45 | 0.3 | 3m | 4.78 | 5.25 | CHIPS OR DIE,6-Lead LFCSP (2.05mm x 2.05mm w/ EP) |
HMC7447 | 71G | 86G | 24 | 0.5 |
| 3 | 5 | CHIPS OR DIE |
LTC5564 | 600M | 15G | 40 | 2 | 44m | 3.1 | 5.5 | 16-Lead QFN (3mm x 3mm x 0.75mm w/ EP) |
LTC5536 | 600M | 7G | 38 | 1 | 2.1m | 2.7 | 5.5 | 6-Lead TSOT-23 |
LTC5535 | 600M | 7G | 42 | 1 | 2m | 2.7 | 5.5 | 6-Lead TSOT-23 |
LTC5530 | 300M | 7G | 42 | 1.2 | 500μ | 2.7 | 6 | 6-Lead TSOT-23 |
LTC5533 | 300M | 11G | 40 | 1 | 900μ | 2.7 | 6 | 12-Lead DFN (4mm x 3mm w/ EP) |
LTC5532EDC | 300M | 12G | 42 | 1.2 | 500μ | 2.7 | 6 | 6-Lead TSOT-23,6-Lead DFN (2mm x 2mm w/ EP) |
LTC5532ES6 | 300M | 7G | 42 | 1.2 | 500μ | 2.7 | 6 | 6-Lead TSOT-23,6-Lead DFN (2mm x 2mm w/ EP) |
LTC5509 | 300M | 3G | 36 | 0.5 | 580μ | 2.7 | 6 | 6-Lead SC70 |
LTC5531 | 300M | 7G | 42 | 1.2 | 500μ | 2.7 | 6 | 6-Lead TSOT-23 |
LTC5507 | 100k | 1G | 48 | 1 | 550μ | 2.7 | 6 | 6-Lead TSOT-23 |
LTC5508 | 300M | 7G | 44 | 2 | 550μ | 2.7 | 6 | 6-Lead SC70 |
LTC5505-1 | 300M | 3G | 46 | 1 | 500μ | 2.7 | 6 | 5-Lead TSOT-23 |
LTC5505-2 | 300M | 3.5G | 44 | 1 | 500μ | 2.7 | 6 | 5-Lead TSOT-23 |
